ZQS/ZYS Series Herb Sterilizer Summary:
ZQS/ZYS series herb sterilizer is specifically for the high temperature sterilization, drying of herbal, Chinese medicine powder, spices, etc. The herb sterilizers adopt clean steam as sterilization medium. Operated by special sterilization process. The sterilization equipment eliminates the influence of cold air on the temperature by pulse vacuum, vacuum dehumidification combined with jacket heating for drying. The sterile air is exhausted to achieve pressure balance. For some products that have high drying effect requirement, the equipment can also be installed with heating coil.
Herb Sterilizer Structure:
The herb sterilization equipment adopts double layer horizontal rectangular structure, 304 or 316L stainless steel chamber. The sterilizer has high-quality vessel plate or 304 stainless steel jacket, and covered by the external plate that is made by draw-benched stainless steel. The equipment is accessorized with standard GMP verification interface. Industrial control system PLC + HMI is equipped with standard “user management, data storage, process management” function. The sterilization process can be traced back, with independent data recording device and industrial control system to ensure data accuracy. Temperature time and Fo dual control meet national pharmacopoeia requirements.
Herb Sterilizer Parameter Table:
| Main Parameter / Model | ZQS0.25 | ZQS0.36 | ZQS0.6 | ZQS0.8 | ZQS1.0 | ZQS1.2 | ZQS1.5 | ZQS2.0 | ZQS2.5 |
| Volume | 0.25m³ | 0.36m³ | 0.6m³ | 0.8m³ | 1.0m³ | 1.2m³ | 1.5m³ | 2.0m³ | 2.5m³ |
| Chamber Measurement | 800×600×600 | 1000×600×600 | 1200×610×910 | 1450×610×910 | 1250×680×1180 | 1500×680×1180 | 1900×680×1180 | 1700×1000×1200 | 2100×1000×1200 |
| External Measurement | 1100×1320×1700 | 1300×1320×1700 | 1500×1320×1950 | 1750×1320×1950 | 1550×1420×2000 | 1820×1420×2000 | 2200×1420×2000 | 2000×1880×2000 | 2400×1880×2000 |
| Steam | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa | 0.4-0.8Mpa |
| 15kg | 20kg | 30kg | 40kg | 50kg | 55kg | 60kg | 70kg | 80kg | |
| Water | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa | 0.15-0.3Mpa |
| 100kg | 100kg | 200kg | 200kg | 300kg | 300kg | 300kg | 400kg | 400kg | |
| Compressed Air | 0.5-0.8Mpa | 0.5-0.8Mpa | 0.5-0.8Mpa | 0.5-0.8Mpa | 0.5-0.8Mpa | 0.5-0.8Mpa | 0.5-0.8Mpa | 0.5-0.8Mpa | 0.5-0.8Mpa |
| Power | 3KW | 3KW | 3KW | 4KW | 4KW | 4.5KW | 4.5KW | 5.5KW | 5.5KW |
| Weight | 900kg | 1000kg | 1350kg | 1650kg | 1850kg | 2000kg | 2200kg | 2600kg | 3200kg |
| Design Pressure | 0.245MPA | ||||||||
| Design Temperature | 139℃ | ||||||||
